OSV/SOV Midship Section

Discussion in 'Boat Design' started by bateaudemoi, Jan 28, 2021.

  1. bateaudemoi
    Joined: Jul 2019
    Posts: 17
    Likes: 3, Points: 3
    Location: Canada

    bateaudemoi Junior Member

    Hi all,

    Wondering if anyone would be able to share any structural midship drawings for offshore supply/support operations vessels.
    I've done a lot of poking around google and I've found bits and pieces, but nothing really complete.
    I've asked in here before about a tugboat midship section and someone was nice enough to share so I figured it was worth another shot.

    Cheers, and thanks in advance.

  2. bajansailor
    Joined: Oct 2007
    Posts: 3,599
    Likes: 1,562, Points: 113, Legacy Rep: 37
    Location: Barbados

    bajansailor Marine Surveyor

    Are you looking for drawings that are art quality, worthy of being framed and hung on your wall, or drawings for reference re designing an OSV of your own, or ???
    If the latter, then if you come up with some initial dimensions, you should then be able to get some basic scantlings from applying class rules?

  3. cthippo
    Joined: Sep 2010
    Posts: 813
    Likes: 52, Points: 28, Legacy Rep: 465
    Location: Bellingham WA

    cthippo Senior Member

    I have some drawings for an AHTS. Does that help?
    Plan_01.jpg Plan_02.jpg Plan_04.jpg Plan_06.jpg Plan_07.jpg Plan_08.jpg Plan_09.jpg


    Attached Files:

    bajansailor likes this.
