Bow thruster installation

Discussion in 'Propulsion' started by Vronsky, Jan 20, 2020.

  1. Vronsky
    Joined: Apr 2014
    Posts: 43
    Likes: 0, Points: 6, Legacy Rep: 10
    Location: Amsterdam

    Vronsky Junior Member

    Was visiting BOOT in Dusseldorf this weekend, and noticed how bow thrusters in mass production motor boats are installed these days, here's an example >>

    Bow thruster on the stern of a motor boat - ship mooring thrusters - Koop deze stockfoto en ontdek vergelijkbare foto's op Adobe Stock https://stock.adobe.com/nl/images/bow-thruster-on-the-stern-of-a-motor-boat-ship-mooring-thrusters/257173748

    Please note those 'seams' below the opening, as if the pipe has been sort of 'cut' into the hull...
    The construction doesn't seem to be the usual pipe that's inserted into the hull.

    Does anyone know more about this construction ??

    THANKS,
    V.

  2. Ad Hoc
    Joined: Oct 2008
    Posts: 6,564
    Likes: 580, Points: 113, Legacy Rep: 2488
    Location: Japan

    Ad Hoc Naval Architect

    No images in the link?

  3. BlueBell
    Joined: May 2017
    Posts: 1,212
    Likes: 219, Points: 63
    Location: Victoria BC Canada

    BlueBell Ahhhhh...

    I saw images both times I opened the link.

  4. Ad Hoc
    Joined: Oct 2008
    Posts: 6,564
    Likes: 580, Points: 113, Legacy Rep: 2488
    Location: Japan

    Ad Hoc Naval Architect

    This is all I see:


  5. bajansailor
    Joined: Oct 2007
    Posts: 1,119
    Likes: 290, Points: 83, Legacy Rep: 37
    Location: Barbados

    bajansailor Marine Surveyor

    I can see the photos here - but everything is written in Dutch, whereas Ad Hoc's appears to be in English?

    <mod note: removed now that Ad Hoc has seen them; appreciate the desire to help, but attaching Stock photos themselves to a forum post here would seem to violate Adobe's copyright on the stock photos.>

    Ad Hoc likes this.
  6. Ad Hoc
    Joined: Oct 2008
    Posts: 6,564
    Likes: 580, Points: 113, Legacy Rep: 2488
    Location: Japan

    Ad Hoc Naval Architect

    Ahh....thanks Bajansailor :cool:

    The recess, or cut into the hull as you cite, is down to the shape of the hull and not wanting to disturb the flow of water past the orifice. Since at speed an orifice like this will or could or can create turbulence/eddies. It can be noisy as well as loss of speed and erosion issues.
    So it is recessed slightly and the shape leading to and/or from the orifice is tapered to the hull shape to prevent the aforementioned.

    bajansailor likes this.
  7. bajansailor
    Joined: Oct 2007
    Posts: 1,119
    Likes: 290, Points: 83, Legacy Rep: 37
    Location: Barbados

    bajansailor Marine Surveyor

    Ooops - apologies to the Moderator for doing that, I certainly didn't think for a moment that there would be any conflict as a result of me posting these photos.
    But I can see your reasoning - folk do get very uppity about copyrights (and possible litigation) nowadays.

    BlueBell likes this.
  8. Ad Hoc
    Joined: Oct 2008
    Posts: 6,564
    Likes: 580, Points: 113, Legacy Rep: 2488
    Location: Japan

    Ad Hoc Naval Architect

    Im not sure?
    I have Adobe professional, so I don't know why I couldn't view them. If they are "locked" for some copyright/privacy issue, then why post them on a public forum?
    Doesn't make sense either way really....
    What you did was perfectly fine as far as I could see.

  9. Boat Design Net Moderator
    Joined: Feb 2010
    Posts: 509
    Likes: 104, Points: 43, Legacy Rep: 1004
    Location: www.boatdesign.net

    Boat Design Net Moderator Moderator

    I don't think it's related to why they weren't viewable for you on the stock.adobe.com website -- the image appeared fine for me on the link above, so maybe something relating to location or a temporary issue with a CDN that site is using serving your region maybe.

    However, I want to be careful not to violate Adobe's Terms of Service which I don't think would allow their stock photos to be attached to a forum post here unless a specific license was purchased for each stock photo in question.

    bajansailor and BlueBell like this.
  10. Ad Hoc
    Joined: Oct 2008
    Posts: 6,564
    Likes: 580, Points: 113, Legacy Rep: 2488
    Location: Japan

    Ad Hoc Naval Architect

    My bad. My phishing/spam/ad blocker...ive just noticed it blocking the links.
    Once i allowed the link to view fully.... i see all the images now.
    Doh! :oops:

    bajansailor likes this.

  11. Vronsky
    Joined: Apr 2014
    Posts: 43
    Likes: 0, Points: 6, Legacy Rep: 10
    Location: Amsterdam

    Vronsky Junior Member

    The fairing behind the orifice serves to reduce turbulence > hard to believe those vertical 'seams' are meant to do the same.
    Still think there's some reason in the manufacturing process behind it.
